Rotart evaporator

A rotary evaporator is a device used in chemical laboratories for the efficient and gentle removal of solvents from samples by evaporation. Rotary evaporation is most often and conveniently applied to separate "low boiling" solvents such a n-hexane or ethyl acetate from compounds which are solid at room temperature and pressure. However, careful application also allows removal of a solvent from a sample containing a liquid compound if there is minimal co-evaporation (azeotropic behavior), and a sufficient difference in boiling points at the chosen temperature and reduced pressure.

Rotart evaporator
Rotart evaporator
Rotart evaporator
Rotart evaporator
Rotart evaporator
Rotart evaporator
  • Detail picture


  • Table parameters
    ModelRE-1006

    RE-1010

    RE-1020RE-1030RE-1050

    Optimum Ambient Temperature(℃)

    5-25

    Power(V/Hz)

    220V/50/60Hz Single-phase

    220V/60Hz Single-phase(Customizable)

    Speed regulation of main engine

    Digital DC Stepless speed regulation

    Rotate speed of main engine(rpm)

    10-200

    20-12010-140

    10-200

    Rotary motor power(W)

    4060120

    Maximum vacuum degree(Pa)

    399.9 Pa (under 3mmHg)

    Rotary flask(L)

    25102050

    Receiving flask(L)

    1351020

    Condenser

    Vertical Dual Coil

    Main Condenser+Auxiliary condenser

    Evaporative capacity(L/h)

    Water1

    Water2

    Water3.2

    Water5

    Water9

    Alcohol≥3

    Alcohol≥4

    Alcohol≥6.5

    Alcohol≥11

    Alcohol≥19

    Water bath pot materialStainless Steel

    Lifting stroke(mm)

    0-120

    0-1500-1600-1800-190

    Complete machine power(kw)

    1.52356.5

    Dimension (W*H*D mm)

    660*830*420765*1070*400920*1700*5501250*1200*6001320*2340*770
